Piezoelectric positioning system technology for modulation of electrochemical imaging detection
device
Wei Wang
Changchun Institute of Applied Chemistry Chinese Academy of Sciences, China
The piezoelectric ceramic positioning system is considered to be the high-precision positioning device in the electrochemical
imaging detector, which can achieve the nanometer scale displacement resolution. This paper describes in detail the
principle of output displacement measuring for piezoelectric ceramic by the resistance strain gauge. In addition, by employing
the self-built drive circuit and the displacement detecting circuit, integrated piezoelectric ceramic resistance strain gauge sensor
has been investigated under both open-loop and closed-loop control, respectively. Under the closed-loop control testing, with a
classic PID algorithmwas applied. Test results show that, the piezoelectric ceramics in open-loop control exhibits disadvantages
of serious non-linearity, hysteresis and creep resistance. However, these issues have been resolved under closed-loop control.
Biography
Wei Wang is an Associate Professor, Master of Electronic Engineering, graduated from Jilin University. He has designed and developed a variety of analytical
detection equipments and obtained progress Award of Jilin Province Science and Technology in nano-structured composites and analysis instrumentation aspects
in 2008.
