Sustainable Water-Energy-Environment Nexus for Thermal Bioenergy Conversion
Jinying Yan
1
, Zhi Zou
1
, Hailong Li
2
, Eva Thorin
2
and
Daniel Billstrom
3
1
KTH Royal Institute of Technology, Sweden
2
Mälardalen University, Sweden
3
Mälarenergi AB, Västerås, Sweden
A
concept of sustainable water-energy-environment nexus has been developed for thermal bioenergy conversion processes
as shown in Figures 1 and 2. Two case studies are performed in a biomass-fired CHP plant and a waste incineration
unit, which intend to approve and implement the concept. The main results from the case study on stormwater issues in
biomass-fired CHP plant show that the biomass fuel storage can play an important role in the sustainable development for
the water-energy-environment nexus. It has been proved that the water adsorption capacity of wood chips can be used as a
buffer to reduce water runoff, to extend the time for natural water evaporation, to receive the recycled runoff water without
significant impacts on fuel quality. The runoff water absorbed by the biomass fuels could increase heat recovery and water
reuse. The results also indicate that it is possible to achieve near zero water runoff and wastewater emissions in the tested plant
area by an integration of stormwater management with the bioenergy conversion processes. Another case study is focused on
a closed water loop in Waste-to-Energy (waste incineration) unit. The closed water loop can properly integrate the thermal
energy conversion with an efficient flue gas cleaning, cost-effective water treatment and energy-effective water recovery. The
investigation shows that it is possible to achieve a near zero wastewater discharge, which could also result in a significant
amount of water recovery for internal usage. The two case studies demonstrate that sustainable water-energy-nexus could be
set up in biomass energy conversion processes, which can provide good solutions handle important issues associate with water
resource, energy efficiency and emissions to air and waters in bio energy conversion processes.
Figure 1.
Illustration of the concept development for a sustainable water-energy-environment nexus in thermal bioenergy conversion processes
Figure 2.
Minimising storm water discharge could be achieved by a water balance through water retention, water evaporation in biomass fuel storage. The
recirculated runoff water by biomass fuels can further enhance heat and water recovery in flue gas condensation.
Recent Publications
1. Galanopoulos C, Yan J., Li H, Liu L (2018) Impacts of acidic gas components on combustion of contaminated
biomass fuels. Biomass and Bioenergy 111:263-277.
2. Li H, Tan Y, Ditaranto M, Yan J, Yu Z (2017) Capturing CO2 from biogas plants. Energy Procedia 114:6030-6035.
3. Larsson M, Yan J, Nordenskjöld C, Forsberg K, Liu L (2016) Characterisation of stormwater in biomass-fired
combined heat and power plant – Impacts of biomass fuel storage. Applied Energy 170:116-129.
4. Zhang X, Yan J, Li H, Chekani S, Liu L (2015) Investigation of integration between biogas production and
upgrading. Energy Conversion and Management 102:131-139.
5. Sun Q, Li H, Yan J, Liu L, Yu Z, Yu X (2015) Selection of appropriate biogas upgrading technology - A review of
biogas cleaning, upgrading and utilisation. Renewable & Sustainable Energy Reviews 51:521-532.
Biography
Zhi Zou is an PhD student of Chemical Engineering and Technology at KTH Royal Institute of Technology, Stockholm, Sweden.
zhizou@kth.seJinying Yan et al., J Bioremediat Biodegrad 2018, Volume 9
DOI: 10.4172/2155-6199-C1-015
