Volume 8

Journal of Biotechnology & Biomaterials

ISSN: 2155-952X

Biotech Congress 2018 & Enzymology 2018

March 05-07, 2018

Page 57

Notes:

conference

series

.com

JOINT EVENT

Global Congress on

Biotechnology

International Conference on

Enzymology and Molecular Biology

March 05-07, 2018 London, UK

Ibrahim Abdulhalim, J Biotechnol Biomater 2018, Volume 8

DOI: 10.4172/2155-952X-C2-090

Plasmonic biosensors on demand: Tunable penetration depth, compactness, ultrahigh sensitivity

and enhanced spectroscopies

vanescent wave optical biosensors allow specific sensing by using a surface binding layer which enhances the capture

of specific bio-entities within the nanoscale neighborhood to the sensor surface. However, this evanescence region is

sometimes too small at the scale of few tens of nanometers which prevents obtaining monotonic signal versus concentration

when the bio-entities are larger than the optical penetration depth. The purpose of this study is to describe methods for

sensing both small (molecules, viruses, etc.) and large bioentities (cells, large molecules) using plasmonic sensors with

tunable penetration depth. During the last few years, we have been developing different structural and system configurations

for improving the performance of plasmonic biosensors based on improving the reading method and enhancing the local

electromagnetic (EM) field further for the purpose of improving the sensitivity and lowering the detection limit based on

SPR, SERS and SEF. The structural improvements include: (i) planar thin metal films combined with dielectric films, (ii)

periodic metallic structures on planar substrate, (iii) nanosculptured thin films prepared by the glancing angle deposition

technique. (iv) long range self-referenced plasmonic configurations, and lately, (v) combination of nanostructures with thin

metal films for coupling of extended surface plasmons (ESP) to localized surface plasmons (LSP). The system improvements

include: (i) diverging beam approach in the angular mode, (ii) polarimetric spectral mode, (iii) image and signal processing.

Particularly, we have shown recently that even much higher enhancement of the EM fields is obtained by exciting the LSPs

through extended surface plasmons generated on a semi-infinite metallic film surface. Biotechnology applications will be

presented for sensing biomolecules and cells in water and in blood. In spite of the technological advances in optics, the need

for developing molecular binding layer to improve the specificity is still in demand from the biotechnology community.

Biography

Ibrahim Abdulhalim is a Professor at the Electro-optical Engineering Unit at Ben-Gurion University of the Negev. He worked in academic institutions and companies such

as the OCSC in University of Colorado Boulder, the ORC at Southampton University, the Thin Films Center of the University of Western Scotland, in KLA-Tencor, Nova and

GWS Photonics. He has published over 200 articles, two books, 10 chapters and has 20 patents. He is a fellow of IoP and SPIE and an Associate Editor for the

Journal

of NanoPhotonics

and for the

Journal of Imaging

abdulhlm@bgu.ac.il

Ibrahim Abdulhalim

Ben-Gurion University of the Negev, Israel
