MR Findings of Exercise-Induced Rhabdomyolysis: A Case of 14-Year-Old Boy

Case Reports Open Access
Atsushi Isozaki*, Aki Tanaka and Nobuyuki Kikuchi
Department of Pediatrics, Yokohama City Minato Red Cross Hospital
*Corresponding authors: Atsushi Isozaki
Departm ent of pediatrics
Yokohama City Minato Red Cross Hospital
3-12-1 Shinyamashita, Naka-ku
Yokohama 231-8682, Japan
Tel: 81-45-628-6100
Fax: 81-45-628-6101
E-mail: isozaki.ped@yokohama.jrc.or.jp

Received March 24, 2012; Published August 24, 2012

Citation: Isozaki A, Tanaka A, Kikuchi N (2012) MR Findings of Exercise-Induced Rhabdomyolysis: A Case of 14-Year-Old Boy. 1: 264. doi:10.4172/scientificreports.264

Copyright: © 2012 Isozaki A, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

Abstract

We experienced a 14-year-old boy case of exercise-induced rhabdomyolysis presumably complicated by heatrelated illness and obtained MR findings on the onset and healing period of the disease. On MR imaging, inner muscles of thigh revealed high signal on T2 weighted images. MR findings can help to specify affected lesions and MR imaging is considerable examination.

Keywords

Rhabdomyolysis; Magnetic Resonance Imaging; Heat Exhaustion

Introduction

It has been described that rhabdomyolysis is a complication of heat-related illness. So far, Magnetic Resonance (MR) findings of rhabdomyolysis have been reported. We experienced a case of exerciseinduced rhabdomyolysis presumably complicated by heat-related illness and obtained MR findings on the onset and healing period of the disease. MR findings revealed normal intensity, previously recognized high signal on T2-weighted image was disappeared on 22nd day after the onset.

Case Report

A well-nourished 14-year-old boy presenting upper leg pain after training basketball was transported to our pediatric emergency department. The room temperature was up to more 35 degrees centigrade in this day. On arrival at the hospital, his consciousness was clear but he could not walk by himself because of pain. His body temperature was 36.7 degrees centigrade. He complained of pain in the bilateral thigh, but those were normal by appearance without swelling and redness. On examination, although his sensory of upper and lower limbs were intact, and motion of ankle joints were as usual, he could barely move his knees because of the pain.

The laboratory data were as follows : creatinin kinase 10,491 IU/L, asparate transaminase 236 IU/L, lactate dehydrogenase 448 IU/L, white blood cells 14,8200/μL ; and electrocytes were normal, acidemia was not presented. His first urination was coke-like color and urinary occult blood reaction was three plus, but red blood cells were not detected on the sedimentation. The protein of urine reaction was 2 plus. We diagnosed him as rhabdomyolysis and he was admitted to our hospital for the purpose of hydration therapy to prevent progression to the renal failure.

The next day, creatinin kinase level was elevated up to 29,302 U/L and aldorase revealed 995 U/L so as asuparate transferase up to 1,401 IU/L. The reaction test for occult blood of urine was negative. On MR imaging, inner muscles of thigh revealed high signal on T2 weighted images (figure 1). The value of creatinin kinase was getting lower. The value of alanine aminotransferase was up to 541 IU/L on 4th day after admission, reflected by heat related illness, but its value was gradually dropped so as creatinin kinase and asparate transferase. His pain was gradually reduced and regained normal gait. He had not fallen into renal failure. He was discharged from our hospital on 9th day after admission.

Figure 1: T2-Weighted Findings on the Next Admission Day Revealed High Signal Lesions of Inner Muscles of the Left Thigh (White Arrow).

After discharge, the values of creatinin kinase, aldorase, asparate transferase and alanine aminotransferase were normalized on 15th day of onset. MR findings revealed normal intensity, previously recognized high signal on T2-weighted image was disappeared on 22th days after the onset (figure 2).

Figure 2: T2-Weighted Findings Revealed Previous High Signal Disappeared and were Normalized to Isointence on 22 Days after the Onset.

Discussion

It has been described that rhabdomyolysis is a complication of heat-related illness. And exercise-induced rhabdomyolysis including adolescent has been previously reported [1-9]. Those were induced by strenuous activities as military basic training, weight lifting, and marathon running and football practice.

Rhabdomyolysis is defined as an injury to the skeletal muscle resulting in myolysis with subsequent leakage of intracellular contents such as myoglobulin, potassium, creatinin phpsphokinase, aldorase, lactate dehydrogenase, into the plasma. The presentation of rhabdomyosis is characterized by the triad of myalgias, muscle weakness and darkened urine. Patient with rhabdomyolysis are at risk factor for developing into acute renal failure and are associated with abnormalities of metabolic acidosis, hyperphosphatemia and hyperkalemia. Large amount of intravascular hydration is needed to prevent acute renal failure. Intravenous saline restores intravascular volume and induces solute diuresis. Acute renal failure chould be prevented by large amount of infusion in this case.

MR findings of rhabdomyolysis have been reported. T2-weighted magnetic resonance imaging, more fat-suppressed T2-weighted imaging, was useful for depicting rhabdomyolysis lesions that show high intensity. Kakuda et al. [10] described that Gadoliniumenhanced postcontrast T1-weghted imaging demonstrated lesions more definitively than T2-weghted imaging in the chronic phase of rhabdomyolysis [11]. Described magnetic resonance imaging had a higher sensitivity in the detection of abnormal muscles than Computed Tomography (CT) and ultrasonography.

Lu CH et al. described recently that rhabdomyosis is a clinical and biochemical syndrome comprising of 2 distinct imaging [12]. Homogeneous signal changes and enhancement in the affected muscles advocate type 1 rhabdomyolysis. The affected muscles revealed homogeneously isointense to hyperintense on T1-weighted, homogeneously on T2-weighted and Short-Tau Inversion Recovery (STIR) images, and homogenously enhanced on contrast-enhanced MR images. The “stipple sign” is useful in demonstrating the area of myonecrosis in type 2 rhabdomyolysis. The affected muscles revealed homogeneously or heterogeneously isointese to hyperintense on T1-weighted images, heterogeneously hyperintese on T2-weighted and STIR images, heterogeneously hypodense on CT images, and rim enhanced on contrast-enhanced MR and CT images with the presence of a specific presentation, named as “stipple sign”. In our case, type 1 rhabdomyolysis was suggested because of MR findings and clinical course, although neither contrast-enhanced MR nor CT was demonstrated Shintani S et al. described that repeat MR studies of rhabdomyolysis resolved in parallel with the improvement of the clinical course [13]. They suggested that this reversivility of the MR findings suggests the high intensity lesions did not reflect permanent myopathic changes, but probably represent transient edema in acute phase of rhabdomyolysis. They reported that MRI images on 15 to 33 days after initial study were normalized as the values of creatinin kinase were decreased. The value of creatinin kinase was normalized on 15th day after onset and repeat MR findings on 22th day revealed normal intensity in our case.

Pediatricians may experience the case of exercise-induced rhabdomyolysis with or without complication of heat-related illness. Many cases can be diagnosed by clinical history, physical examination and laboratory data. However, MR findings can help to specify affected lesions and MR imaging is considerable examination. Further more, new classification of MR findings of rhabdmyolysis was advocated; MR findings may play a role of the consideration of pathogenesis.
