The bucket handle affects about 10% of meniscal injuries. It is predominant in young subjects and on the internal meniscus. This is an extensive longitudinal post-traumatic lesion separating the meniscus into a peripheral segment integral with the capsule and an unstable medial segment which can dislocate in the intercondylar notch [1]. Often in the course of trauma, the patient generally complains of clicking, sharp pain and especially blockage in the extension of the knee, which is the main symptom. The diagnosis is mainly based on MRI.

On MRI in sagittal slices, we can find the sign of the posterior double cruciate ligament (PCL) which corresponds to a meniscal fragment displaced in the intercondylar notch generally parallel to the posterior cruciate ligament (Figure 1). The meniscal fragment is displaced anteriorly and inferior to the LCP. This is a not very sensitive but very specific sign of a meniscal rupture in a bucket handle [2]. Another possible aspect is that of the anterior double horn showing a posterior fissure with residual central attachment and a meniscal fragment dislocated anteriorly. The fragment can also dislocate laterally from the anterior horn and create an anterior megacorn [3]. In axial sections, the meniscal fragment appears sinuous in the notch and folded back on itself (Figure 2) [4]. In coronal slices, the body of the meniscus is truncated, small in size with individualization of a meniscal fragment in the mesial compartment or displaced in the intercondylar notch (Figure 3) [2]. Currently, the treatment of a meniscal rupture in a bucket handle is mainly arthroscopic surgery.

Figure 1: Meniscal rupture in a bucket handle. MRI in sagittal section 3D cube sequence with fat saturation showing a meniscal fragment dislocated in the notch in hypo signal, parallel to the posterior cruciate ligament and achieving a posterior double cruciate appearance.

Figure 2: Meniscal rupture in a bucket handle. Axial MRI 3D cube sequence with fat saturation showing a sinuous meniscal fragment in the intercondylar notch.

Figure 3: Meniscal rupture in a bucket handle. Coronal MRI 3D sequence with fat saturation. Vertical meniscal fissure with dislocation of a meniscal fragment in the intercondylar notch.
