Otitis media with effusion (OME) is one of the most common disorders of childhood [1]. Bluestone and Klein defined OME as an inflammation of the middle ear with a collection of fluid in the middle ear space [2]. The amount and nature of fluid found in OME is highly variable. The fluid may partly or completely fill the tympanomastoid compartment and can be serous, mucoid or glue like [3,4].

Diagnosis of OME is based on three factors: patient history, otoscopic examination of the TM and audiological evaluation that includes tympanometry and pure tone audiometry [5]. Tympanometry is the best objective evidence of a middle ear effusion [6,7]. It measures changes in the acoustic admittance of the ear as a function of the pressure in the sealed external ear canal. The curve of a tympanogram is defined by 3 major characteristics: 1) the maximum acoustic admittance of the ear, which is the value of the admittance at the peak of the tympanogram (may be compensated for the ear canal volume); 2) the pressure at the peak of the tympanogram, which reflects the pressure in the middle ear; and 3) the gradient, which represents the flatness of the curve [5,8].

Jerger [8] classified tympanograms as types A, B and C. Types A and C are characterized by the presence of a peak, which is close to 0 decapascals (dapa) in type A and negative (equal to or less than -100 dapa) in type C. In type B tympanogram, there is no distinct peak and the admittance does not significantly change during pressure variations in the external ear canal. Type B tympanogram may be either straight or with a pseudopeak (round B). In clinical practice, type B is generally related to fluid in the middle ear [5,9].

Objective

To correlate the characteristics of type B tympanogram with the type of middle ear fluid in children suffering from persistent OME.

A prospective study was done in the ENT Department at Sohag University Hospital, Egypt, over one year duration between September 2015 and September 2016.

Subjects

Children (under the age of 12 years, either males or females) with persistent OME for more than 3 months who failed to respond to medical treatment, with type B tympanogram in one or both ears and are candidate for myringotomy were randomly included in our study. Those children complaint mainly from, diminution of hearing, nasal obstruction or snoring. The exclusion criteria include children with extensive tympanosclerosis, scarred TM, adhesive otitis media or those who revealed purulent aspirate.

The study was done after approval from Sohag Faculty of Medicine Ethics Committee. Informed consents were obtained from the parents of all children who agreed to participate in this study. All children were subjected to a careful history taking and full ENT examination including otoscopic examination, pneumatic otoscopic examination (Welch Allyn otoscope).

The tympanometer (Mico 41) was performed using a 226 Hz probe frequency with positive to negative pressure sweeps of 600 daPa/s. Only type B tympanograms were interpreted as pathological. Those with type B tympanogram and failed to respond to medical treatment for 3 months were included in the study. At the day of surgery tympanometry was repeated and those with type B were subjected to myringotomy under general endo-tracheal anesthesia and the middle ear fluid was aspirated into a 3 ml syringe mounted on the aspiration cannula and the viscosity of the fluid was evaluated objectively to add to the subjective surgeon's opinion. 0.2 ml of the aspirated fluid was applied to the center of a filter paper and left flat for 5 min inside a glass container to allow for diffusion of fluid contents of the aspirate. Then, the diameter of the diffusion circle was measured in mm. Similarly, 0.2 ml of water and of aspirated nasal mucus in normal volunteers was applied to filter papers to measure the diameter of diffusion circles of both as a control. The mean water diffusion diameter is taken as a control reference of serous MEE and the nasal aspirate diffusion diameter is taken as a control reference of mucoid MEE. Correlation between the tympanometric results and type of ME secretions was done using the correlation coefficient test via the SPSS program. P-values<0.05 were considered significant.

Over a one year period, 38 children (70 ears) were included in this study with an age range from 1.25 to 12 years with a mean of 4.61 years. They were 22 males (57.89%) and 16 females (42.11%).

In our study, there were 28 (73.68%) cases having adenoid with encroachment on the nasopharyngeal opening of the ET, five patients of those with adenoids presented only with snoring/nasal obstruction with no otologic symptoms despite having OME. Seven (18.42%) cases had previous history suggestive of AOM.

Characters of tympanometry

Shape: Shape of type B tympanogram in this study was either flat in 47 ears (67.14%) or peaked tympanogram in 23 ears (32.86%).

Pressure: Mean value was -17

Compliance: Mean value was 0.14

Gradient: Mean value was 312

Characters of the fluid: The mean diffusion diameter of water was 30 mm (Figure 1) and the mean diffusion diameter of nasal aspirate was 5 mm (Figure 2). The diffusion diameter ranged from 4-31 mm. We classified the type of secretions according to the diffusion diameter into:

Figure 1: Measurement of the diffusion diameter of water in mm (31 mm).

Figure 2: Measurement of the diffusion diameter of aspirated nasal mucoid discharge in normal volunteer (5 mm).

Serous effusion: With a diffusion diameter of 25-31 mm (Figure 3)

Figure 3: The diffusion diameter of serous ME effusion (31 mm).

Mucoid effusion: With a diffusion diameter of >5-<25 mm (Figure 4)

Figure 4: The diffusion diameter of mucoid ME effusion (23.5 mm).

Glue effusion: With a diffusion diameter of ≤ 5 mm (Figure 5)

Figure 5: The diffusion diameter of glue ME effusion (4.5 mm).

Table 1 demonstrates the number and percentage of each type of effusion in the 70 ears.

Table 1: The number and percentage of the type of secretions in the 70 ears.

Correlation study

The correlation between the tympanometric results and types of effusion was demonstrated in Table 2. There was a high statistically significant positive correlation between the type of secretions and the shape of tympanometry. On the other hand, there was a high statistically significant negative correlation between the type of secretions and the character of tympanometry (gradient and compliance).

Table 2: The correlation between the tympanometric results and type of secretions.

The question examined in the present study is whether tympanometry, can clearly differentiate cases with thin fluid from those with thick fluid. If feasible, this differentiation might assist the otologist in determining whether medications or surgery would be more efficient treatment as regards the minimization of delay in the resolution of the effusion and subsequent hearing loss.

The main function of the ET is middle ear ventilation to equalize the middle ear pressure with atmospheric pressure [10]. Mechanical obstruction of the ET because of adenoid hypertrophy may be an important factor in OME [11,12]. Kinderman et al. found that obstruction of the ET orifice by adenoid tissue was associated with tympanograms suggestive of abnormal pressure in the middle ear [13]. In our study, there were 28 (73.68%) cases having adenoid with encroachment on the nasopharyngeal opening of the ET. 7 (18.42%) cases had previous history suggestive of AOM. AOM is more often present in age below 2 years as reported by many authors, 20% of those transforms into OME [14,15].

Variable fluid types of middle ear effusion and variable tympanometric results of type B tympanograms were documented in our study. Difference in the fluid type in different patients and in some cases in different ears in the same patient is without convincing evidence in the literature. In our study, we found tympanometry to be an accurate tool in assessing patients for the presence of fluid in a preoperative setting. Shape of type B tympanogram was either flat in the larger percentage of cases (67.14%) or peaked in the remaining ones. In a correlation study between the shape of type B tympanogram and the type of secretion there was a highly statistically significant positive correlation (Table 2) which means that the more flatness of type B tympanogram the more the viscosity of the secretions. This is in agreement with Maw et al. [16] who reported that when an effusion is present with a peaked tympanogram, it is more likely that the effusion will be serous, whereas with a flat tympanogram the majority of effusions are mucoid. It has been reported that the three parameters of tympanograms, pressure, compliance and gradient correlated with effusion within the middle ear [9]. In the present study, there was a highly statistically significant negative correlation between the type of secretions and the character of tympanometry (gradient and compliance); which means that when compliance and gradient decreased, the secretion will be more viscous. This could be explained by that the value at maximum compliance (peak) on tympanogram presents the pressure within the middle ear. Compliance is associated with mobility of the TM. Since effusion within the middle ear decreases mobility of the TM, low compliance and gradient tympanograms usually imply effusion within the middle ear [17]. Therefore, it has been found that type B tympanograms in Jerger’s classification [8] were associated with effusion.

Tympanometry is a beneficial clinical tool in prediction, diagnosis and management of OME. Characteristics of type B tympanogram were correlated with the viscosity of middle ear fluid. Detailed analysis of type B tympanogram can assist the clinicians in determining the indication of comprehensive treatment.
